Viking Wind Farm Site quardrants

Total area inclosed in red areas: 12800 hectares (32000 acres). Note that the non-enclosed areas are as more concerned with public presentation than being actual non-used site areas. Once you add add access roads, sub-stations, control stations and associated permanent and temporary site infrastructure, the areas between site quadrants could become part of the overall site. Hence the site boundaries give a more realistic view of the total site area.

Site quadrants (January 2008)

Site quadrants for Viking Energy Wind Farm

Taken from Viking Energy Scoping Report. January 2008.
